Portable Autoclave BKM-24 B

This sterilizer uses pressure saturation steam as the gene to kill the bacterium. The article will be kept in airtight vessel and after heating, water will be transferred into saturation steam which will heat and damp the article quickly. After a certain period in constant temperature and pressure surrounding, the bacterium will be killed to satisfaction result. It’s desk-top autoclave sterilizer which is designed for the hospital, clinic, lab, etc.It’s mostly suitable for sterilizing of surgical, dental instruments, glassware, culture medium and biological dressing, food and goods, etc.

Please contact us for ordering our products via CONTACT or Email: info@biopolymix.com

Category:

Features

  • Easy to operate, safe and reliable
  • Self-expanding sealing ring has good sealing performance and can effectively prevent steam leakage
  • Over-temperature and over-pressure automatic protection
  • Immersion electric heating tube, high thermal efficiency, durable stainless steel tube
  • Double groove pressure gauge, double temperature and pressure scale, clear indication, convenient observation and reliable performance
  • Equipped with a water level gauge, if the water level is too low, it will automatically stop heating (anti-dry type)
  • Electric heating or liquefied petroleum gas heating (dual-use type)
  • With self-adjustment function, temperature and time can be adjusted by itself, automatically stop heating and alarm function after sterilization (timing control type)
  • Two safety valves keep double safety (timing control type)

Technical Parameters

Model BKM-P18III BKM-P24III BKM-P18II BKM-P24II BKM-P18I BKM-P24I
Type Timing control type Anti-dry type Dual-use Type
Capacity 18L 24L 18L 24L 18L 24L
Chamber Size(mm) Φ260×270 Φ260×380 Φ260×270 Φ260×380 Φ280×240 φ280×350
Time Setting 0~99 min NO
Temperature Setting 126℃
Consumption 2KW
Power Supply Standard: 220V 50Hz; optional: 110V 60Hz(internal transformer)
Working Pressure 0.142MPa
Packing Size(W*D*H)mm 400*400*670 400*400*770 400*400*670 400*400*770 400*400*430 400*400*530
Gross Weight(kg) 16.5 17.5 16.5 17.5 16 17
